Tube Splicer


  • A machine for splicing unvulcanized inner tubes
  • AMCL-MIDLAND’s comprehensive range of Tube Splicing Machines are acclaimed as the most advanced systems and provide the end user with a range of advantages.
  • Microprocessor based control system simplifies the complex sequences.
  • Reliable ensuring consistent high strength tube joints & tubes durability.
  • Precision knife guidance systems.
  • State-of-the-art knife heat control.
  • Solid state electrical control.
  • Hydraulic adjustment of tube width.

Advance Features

  • Dropping Knife Blades
  • Precision knife guidance systems
  • State-of-art knife heat control
  • Solid state electrical control
  • Hydraulic adjustment of tube width
  • Knife cleaning facility
  • Swash-type hydraulic pump
  • Gravity scrap collection

Technical Data Sheet of Tube Splicer


Model

900

1100

1200

Tube Flat Width Maximum

200 mm 500 mm 750 mm

Tube Flat Width Minimum

20 mm 120 mm 450 mm

Double Thickness Standard Special

20 mm max./28 mm 20 mm max./28 mm 20 mm max./28 mm

Maximum Unspliced Tube Length Standard Special

800 mm/650 mm 800 mm/650 mm 1200 mm

Machine Height (Approx)

1900 mm 1900 mm 2300 mm

Machine Width (Approx)

1600 mm 1600 mm 2100 mm

Machine Depth (Approx)

1600 mm 1600 mm 1700 mm

Nett Weight (Approx)

2500 kgs 2500 kgs 5000 kgs

Tubes Per Cycle

Two One One

Approximate Machine Cycle Time

25-40 Seconds 20-35 Seconds 30-55 Seconds

Electrical Supply

6.5 kW at 415V, 3 Phase, 50 Hertz
